This is a difficult question to answer because it depends on several factors, such as the type of structure being supported and the density of the soil.
The best way to know how much your screw pile foundation will cost is to talk to your local Postech dealer and tell them about your project. They can give you a free and accurate quote that includes installation. They can also schedule the installation during the call.
Yes. There are different ways this can be done, depending on the structure and how high it is off the ground. Your Postech installer will recommend the best pile installation method for your structure.
We recommend a minimum spacing of 12 to 18 inches to install a pile under an existing structure.
Yes. Postech has non-helical piles and adapted base mount systems to create a solid foundation in bedrock.
Also, What happens when you hit a rock?
There are a few things your Postech installer can do if the pile happens to hit a rock:
A solid foundation is key for any building’s longevity and stability. It keeps the structure safe from damage and ensures it lasts a long time. Postech Screw Piles, an innovative alternative to traditional foundations, provide durability without the need for special inspections, working well in different terrains and conditions.
Screw piles are versatile and can be used for a variety of structures, including decks, sunrooms, home extensions, sheds, and even fences. They offer a solid foundation for various applications, showcasing their flexibility and reliability in different construction scenarios.
Postech Screw Piles offer several benefits, including being made of Canadian steel, which supports local production and is environmentally friendly. They don’t require excavation, preserving the surrounding ecosystem, and are reusable and movable.
They’re CCMC certified, ensuring industry safety standards, and feature Thermal Pile technology to prevent movement during freeze-thaw cycles. Additionally, they come with a lifetime warranty (25 years, but expected to last at least 75 years).
No. Postech Screw Piles must be installed by certified installers with the necessary training and equipment to ensure a foundation that can solidly support your structure for life.
Postech installers frequently work with homeowners, contractors, engineers, and architects. They can ensure a fast and flawless installation.
No. All Postech Piles are hot-dipped galvanized according to standard ASTM 123A. This also makes Postech Screw Piles better for the environment than non-galvanized steel piles.
Our screw piles stand apart for 5 main reasons:
The ideal distance between piles depends on several factors, such as the span of the beams, soil conditions, etc. Your local Postech installer can advise you on the ideal pile spacing for your project.
Generally, we recommend keeping each screw pile eight (8’) to ten (10’) feet apart, based on industry best practices.
The load or weight that a pile can support depends on the density of the soil. The denser the soil, the higher the pile’s load-bearing capacity.
For very loose soil, we will either use piles with bigger or multiple blades to achieve the necessary torque or add extensions to the pile so that it can be drilled deeper to reach denser soil. Your Postech dealer can determine which option is best for your project.
While installing the last few inches of the screw pile, your Postech installer uses a pressure gauge on the excavator’s arm and a guide chart to confirm the hydraulic pressure and the pile’s load-bearing capacity.
Yes. There must be enough space between the soil and the structure (including trellises, stairs, etc.), to allow for heaving of the soil due to frost.
When the structure is in contact with the soil, this limits the usefulness of the pile because the frost will make the soil heave and move (raise) the structure.
Your Postech installer can recommend the minimum distance for your local soil conditions.
Not with Postech Screw piles. Our galvanized steel piles are already thermally insulated on the inside to prevent cold air from moving down the inside of the shaft. We also install the blade of the pile below the frost line.
This means our piles are completely unaffected by frost heave, so you get a more stable foundation for life.
Absolutely. Postech Screw Piles have been tested against all key industry standards and are approved by the Canadian Construction Materials Centre (CCMC #13102-R). This means that Postech Screw Piles are approved as a construction material in Canada and meet high quality standards as well as building codes.
Always use screw piles that are CCMC approved. Most local and state governments and insurance companies require it.
What’s important is that you know if there are certain installations buried on your property at the locations where you wish to have screw piles installed, (water main, electrical cables, sewer, gas main, or any other underground installations). If you do not know what installations are buried on your property, it will be difficult for our installers to know. Please check with your local municipal government for the location of underground installations.
Yes! We can install piles in virtually any terrain. When you discuss your project with your Postech installer, they’ll be able to determine if any special installation equipment is needed.
Yes. All our Postech screw piles are guaranteed against manufacturing defects and movements due to frost.
We use a variety of installation equipment based on the project, but our standard equipment is a compact Kubota U17 mini-excavator. They are 52 inches wide but can pull into 40 inches when needed.
That means the minimum clearance needed is 40 inches plus a hair.
The useful life of a screw pile depends on the type of soil in which it’s installed and it’s chemical properties (pH, humidity, etc). In average soil, you can expect a pile to last about 75 years.
Your Postech installer will know the type of soil commonly found in your area and can give you a more exact lifespan estimate.
Yes, you need to know if there’s anything buried on the site where the piles will be installed, such as water main, electrical cables, sewer, gas main, or any other underground installations).
If you are unsure, check with your town or city for the location of underground installations on your property.
